  1. Hi all. I know this has been done before, but i am doing this again with a video to make it a bit easier for people to visualise what needs to be done! I have attached a video below of the process of installing the fog lights into your S15 weather they are factory or aftermarket the process is similar. This is a LOT easier and quicker if you have an imported S15 from japan, if you have an ADM (and possible NZD) s15, this process might be a bit longer for you, but will explain your extras in the write up and briefly in the video. Come along for the install! Written Tut! Ok so for those of you who would like some more info, or prefer a read up, here is is in a step by step fashion please drop any questions below! Step 1: You will need the following: - An S15 - A set of factory or aftermarket fog lights - You may also need some 6mm thread nuts and bolts and some washers from memory to mount the lights into the bumper - FOR IMPORTED SILVIA: - You may need an indicator stalk with the fog light switch, else you can follow the ADM/NZ optional Extras to get yours working. (if you are missing the stalk and want one, please PM me on YouTube as i am more likely to see it sooner, or you can PM me here and i will try get back to you as soon as i can with info on how to get one, or if i can source you one) - FOR ADM/NZ MODELS ONLY: - You will need a inline Fuse - Some wire (12 - 14 gauge) - A Switch which Turns you on.. ehem i mean, can be used to Turn on your Fog Lights (Honestly any switch which you would like to use will do, just keep in mind you need to mount this somewhere you can access it) Step 2 (optional): You may want to remove your front bumper for ease of access, or maybe not, i did, good luck should you choose not to Step 2.5: If you are trying to remove your bumper, i have circled the screw location in the video: - There are some near the wheel well closer to the wheel - One inside the bumper up near the light on each side -The ones at the front in between the lights - You may also have some at the bottom if you have a lip, or not Step 3: If your bumper has any mesh or covers where the fog lights go, you will need to remove them at this point. The ones from the non - Aero bar must be unscrewed from the inside, and then slid out from the inside. I assume those on the Aero Bumper are the same (if someone can confirm i will update Thanks) Step 4: Before we mount everything in place, we will test the lights to make sure they work! - If you have an imported SILVIA and are using the factory fog lights, please plug them both into the plugs which you can find around where they will sit on the bumper. If you cannot find the plugs, it is likely you have an ADM or NZ model of the S15, and you will need to do some additional work - If you are using aftermarket fog lights and you have a SILVIA with the plugs, you will need to create an adapter by buying the plug from a wrecker, or online if you can find them, or by using some spade connectors (probably the easiest option as i believe they will fit) - If you are using factory/aftermarket fog lights and you have an ADM/NZ model S15 without the plugs you will need to run wiring to the cabin yourself. Step 4.5(For ADM/NZ Models ONLY): You will need to make your own wiring for this, i am not 100% sure if your s15 comes with the relay or fuse, but no matter, we can do this without any factory wiring, follow the next few steps - You will need to create a plug which goes into your Fog Lights, weather they are factory or aftermarket, you should have 2 wires coming off each at this point. (i would use spade connectors as above but up to you) - You need to choose where you want to draw the power from at this point, You can grab it directly from the battery if you want, probably the easiest way, otherwise you will need to find a fuse you can tap into, i would use the battery but this is up to you. Find your power source. - Wire in your in-line Fuse, i recommend 30 amps, if you believe you know better please do as you like (we don't like fires here...) - Run your wire into the cabin if you are getting power from outside, there is a grommet under the driver side fender which does into driver foot well, run the positive cable into here and then wire in your switch and mount it somewhere accessible to you! - Run the negative off the switch back through the grommet and outside the cabin, into the bay, then rout it down to roughly where your fog lights will be - You will need to split your power source cable and make sure to leave some slack for each connector as you should plug them in before mounting the bumper back - Terminate the wire into either the proper connector or spade connectors (pick your poison) and then join both neg cables back together to make your life easy, and rout the neg to a bolt which connects straight to the chassy to ground the connection. Step 4.6(For SILVIA Import Model From Japan): - If you have an Indicator Stalk with the fog light switch, you do not need to follow the next part of this step - If you do not have the fog light switch on your stalk, you can either buy one and fit it, or follow step 4.5 to install the lights as you would in the ADM/NZ model, or you can do some research to find out where you can tap into the factory wiring in the cabin and just wire the switch in there (i did not go through this so cannot offer much assistance, but if you do go through this, please comment and let us know how you did it, would love to add the info to the Tutorial ) Step 5: Test your lights to see if they Turn on Step 6: If Step 5 was Successful go to step 7, if the lights did not come on, please make sure to check your wiring, or try reversing the polarity as you might have plugged positive into negative on the fog light. If this does not fix your issue, you need to make sure your wire is plugged in and perhaps try using a multi meter to test for power and ground. If you are using factory wiring make sure the fuse and relay are installed in the fuse and relay box Step 7: Unplug your lights and mount them into the bumper (factory will go straight in, just need the mentioned bolts from above) If you have aftermarket lights, you might need to make your own bracket. Step 8: Mount your bumper back onto the car and plug the lights in at the same time Step 9: Clean and final test! Step 10: Profit? Please post some pics below of how yours turned out and what you did. Keen to see outcomes. Please feel free to let me know if there is anything i missed as i would like to make this the most accurate and up to date tut there is. Thanks and good luck!
  2. Hello all and welcome back to another tutorial. I hope you have been well, if you are reading this, we have a video detailing the process just below, and below that we have a write up for those who prefer some good reading material. Today we will be installing the Option B Blue Seats into the S15 Note: Most seats out of all S Chassy's are compatible with one another. If you have an old 180, 240, s13, s14, s15, then all the seats are interchangeable as the rails remain the same. So you can swap new seats into your old car, or if you have a nice set of aftermarket seats, and you're buying a new silvia to sell your old one, then you can slap them right into the new one. Now let's proceed with the installation. If you have aftermarket seats, then you will need to make sure you purchase S-Chassy rails, the bride rails sit well in the s15 and are a nice option. Step 1: You will need to remove the old seats from the car, this is quite straight forward. You will need a socket set, from memory i believe the size of the bolt was 12mm but i cannot remember exactly, as long as your set ranges from 8mm to 18mm you should be fine Step 2: Locate the 4 bolts on each seat. You will find that there are 2 on the floor under the front of the seat, and when you move the seat forward, there are 2 at the back you will need to remove, one will be on the floor and the other against the transmission tunnel. Step 3: I recommend unscrewing the front bolts until they are barely still in the hole, and can be removed with fingers, then sliding the seat forward to remove the rear ones and then you can reach underneath and undo the front ones. but, this is just how i did it, you find a way that suits you Step 4: Tilt the seat backwards, you may see 1 or 2 connectors under there. Most people will only have 1 connector which is used to check if your seatbelt is plugged in, you will need to unplug this to remove the seat. Now you might be special, and have 2 connectors, this is not very likely, but if you are, shoot me a PM if you're removing your seats and you have that yellow connector you have an extra step that needs to be taken Step 5: Gently remove the seat from the car, without breaking anything or scratching anything. Step 6: You might notice that your new/old whatever seats do not have the seat belt buckles on them, before you put them into the car, it would be a good time to remove the buckle off your old seat, and attach it to your new one. should be the same size bolt which is used to anchor the chair to the ground. Step 7: Gently install the replacement seat into the car and pretty much repeat steps 4 to 1 in reverse order. (Again, for those of you with the yellow plug, PM me for step 4.5) Step 8: Make sure all the bolts are nice and tight because this is what saved you from flying through the windshield at a sudden stop or crash Step 9: You're done! If you enjoyed this tutorial, you should consider checking out my other ones. I have quite a few videos focusing on aesthetics for the s15 and i plan to release a few more in the near future. Please also feel free to check out my channel for video guides and vlogs. Thanks for your time. Peace!
  3. Hi guys. This is probably a very commonly covered topic, but today, i wanted to make a video to document the matter, and help those who may not know how to do this. This tutorial will show you how to swap your Coil Packs in your s15 if you find that they are failing, or causing misfire. *Background story - My car was idling fine and such, accel was fine in first 2 gears, but when in 3rd gear upwards, it would stutter and splutter, causing issues with acceleration under boost. I had a tip from some guys on the facebook group, and was told to check my ignition system. I had plans to change coils and plugs, but as i had a spare set of coils, though i would do them first. Changed coils, and did not have to touch my plugs, the issue is now gone. Please follow below for any assistance or instructions. Please see my video for full instructional and visual. For those who might not like watching videos, or tight on data, i will write the instructions below. Please follow closely. If you have a similar issue or need to change your packs, you will need to make sure you have your car turned off. Pop the bonnet, and you may see a silver plate, or a plate of sorts on top of your engine. If you don't have this, you can skip to the next step, if you have one, you will need to remove it with an alan key. Once the silver plate is removed, you will need a 10ml socket to remove the 4 bolts holding the packs in. When unplugging, please be extremely careful, as you can break the clips quite easily if you are too rough, as they are now very brittle after about 20 years of heat cycles. When the plugs are removed from the packs, you can gently pull them up, you may need some force as they have grommets holding them in. When the coils out, at this point, you can just replace it, or you can take it a step further, and change your spark plugs too. I recommend the ngk iridium plugs, they are supposed to last a long time, and are gapped perfectly if you are running a similar setup to me at 15 PSI. If you decided to swap your plugs, make sure not to over tighten them when screwing them in. Once they are in, you can follow the process to swap the coils, but backwards, when installing the new coils. After you have done all this, turn on the car and see if the issue persists, take it for a cruise, and if all is well, congratulations, you have saved a trip to the mechanic! Please feel free to leave me any feedback as it helps me make future content or tutorials! All the best, see you next time!
  4. Hello world! Looking to make a quick tutorial on how to change out your tail lights in the s15 for a set of aftermarket lights. I have attached a video on the process you can view, and I have written the process underneath! Please let me know if you have any questions or feedback. Steps to swapping your tail lights. You will need to first start off by finding a nice set of aftermarket tail lights you would like to install into the car. I have chosen a set of Yashio Full LED tail lights (Apart from the reverse light) There are other nice sets out there too such as the dmax type and sex spec types. I prefer the Yashio ones. Tools you will need: - Phillips head screwdriver - Flat head Screw driver - Socket set (a spanner would work too if you don't have any sockets) - Mine was an 8mm socket, but I believe my nuts are incorrect so yours might be 10mm - You may also need some side cutters for cable ties if you have any Once you have said set of tail lights and tools ready, we will start off by removing the old tail lights. If you open your boot, you will find the where the boot closes, there is a grey strip which runs from the left to the right of the rear of the boot, pictured below. You will need to gently unscrew the Phillips head screws (circled in green), and you will find they cannot be unscrewed any more, just pop them out. You will then have some clips you need to remove, I have circled the points which need to be removed in red, just pop a flat head screwdriver in the tabs and pop them out. There are 2 of these on each side. The grey peace should now lift up and out of the way! Once you have the grey piece out, you will need to remove the 4 nuts holding the old lights in. there are 2 located next to the grommet, and then 2 moving out towards the middle, one is closer than the other. I have attached another image below of roughly where the nuts are located if you are looking down on it, you will see when you are working. you will also need to unplug the white connector going to your lights, I suggest you get a small Flathead and use it to push down on the release latch on the connector if yours are old like mine they can become a pain release. The light should now slide out of its place, make sure you are holding it from the front so you do not drop it Once the light is out, simply reverse the process. If you are installing the Yashio Tail lights like me, you will have a small black box you need to stick to the inside of your boot, and there will be a little plug you need to plug into that too, coming off the lights, simply unplug it to get the cable through the boot and back through the grommet, and then plug it back in once the cables back in the boot (I am not 100% sure what this box is for, initially, I thought it was just to decrease the current and voltage so that it does not fry the lights, but cannot confirm if this is it's only use. It is quite large and would expect such a device to be much smaller. If you know what this is for I would be curious to know Please let me know) Hopefully, you followed through with the tutorial and the new lights look great! Keen to see the results so post up some photos if you followed my tutorial, or even if you just came across it and you have your own lights If you have anything you think I missed and you would like to add, please let me know, I can add it at any time
  5. Hi guys. I have owned my s15 for almost a year now and am finally joining the forum. I am looking to start up a Youtube channel for Vlogs/Tutorials I will start posting some around here soon too! Not that some of the veterans here need the help, but i hope i can reach some people who are new and who are looking for some help! Please feel free to give me some constructive feedback if you feel it's necessary, i love learning myself and sharing the knowledge around. Thanks guys! P.S. The Channel is called Zapp&Crew. I'm still growing so i don't have my own youtube link with the name but you can find us here --> https://www.youtube.com/channel/UCnaQ_AaKIV9qiPnqTutqhJg P.s.s. Would just like to clarify if i am allowed to advertise my Youtube channel in my sig? Thanks
×
